a spatially differentiated life cycle impact assessment method

Ecosystem Quality

Marine Eutrophication

Ecosystem Quality

Marine Eutrophication

Marine eutrophication is defined as the reaction of a marine ecosystem to an excessive availability of a limiting nutrient. The ‘limiting nutrient’ concept implies that it is the availability of the limiting nutrient that determines the extent of the primary production in the ecosystem. Here, we assume nitrogen (N) as the limiting nutrient in marine waters.

Cause-effect pathway

The modelled impact pathway is limited to waterborne (as total-N) loadings from human activities into coastal marine waters increasing its N-concentrations there (Vitousek et al 1997; Galloway et al. 2004). The emission routes can be direct discharge of N into rivers or coastal areas, as well as nitrogen applications to the soil. Airborne emissions are excluded. The N input to marine coastal waters is assimilated by primary producers (mainly phytoplankton), promoting the increase in planktonic biomass (Nixon et al. 1996; Rabalais 2002). The organic matter (OM) thus synthesized is eventually exported to bottom waters (Ducklow et al. 2001) where its aerobic respiration by heterotrophic bacteria results in consumption of dissolved oxygen (DO) (Cole et al. 1988; Diaz and Rosenberg 2008). If excessive amounts of organic carbon reach the benthic (bottom) layer, DO may drop to hypoxic or anoxic levels (Gray et al. 2002), which may then lead to loss of species diversity (NRC 1993; Socolow 1999; Vaquer-Sunyer and Duarte 2008; Levin et al. 2009; Vitousek et al. 2012). The overall model builds on the environmental fate of N-forms, the biological processes in the entire water column of coastal areas, and on the species response to the depletion of DO, assuming linearity of cause-effect relationships along the adopted impact pathway.

picture of Cause-effect pathway Cause-effect pathway for marine eutrophication from anthropogenic emission of waterborne nitrogen

Modeling approach

The environmental mechanism of the impact of N emissions is described by combining (i) environmental fate of N, (ii) exposure of the coastal ecosystem to the nutrient enrichment, (iii) effect of oxygen depletion to exposed species, and (iv) upscaling to global level .The EF modelling based on SSD curves assumes a linear approach to calculate the EFs as no background dissolved oxygen concentrations are known.

Spatial variability

The Large Marine Ecosystems (LME) biogeographical classification system (Sherman et al. 1993) was adopted to address the spatial variation of the modelled parameters among coastal ecosystems and to link the location of the emission sources to 66 spatial units of continental shelves. The CFs are presented for N emissions to soil and freshwater at the level of countries, continents and the world.

Characterisation factors

The endpoint characterization factor, CFend [PDF·yr·kgN-1], for emissions of nitrogen is estimated by

$$\mathsf{CF_{end,ijk}=\sum_j{(FF_{ijk})\cdot (XF_{j})\cdot (EF_{jj})\cdot (VS_{j})}}$$

where FFijk is the Fate Factor [yr] for emissions from country i to receiving marine ecosystem j by emission route k, XFj is the exposure factor [kgO2·kgN-1] in receiving ecosystem j, and EFj is the Effect Factor [PDF·kgO2-1] in receiving ecosystem j. Emission routes (k) include, “N to surface freshwater”, “N to groundwater” (from e.g. applications on agricultural fields), and “N to marine water” (waterborne as total-N). The receiving ecosystems j correspond to the 66 different Large Marine Ecosystems (LME).

For more details, see the report.

References

Cole JJ, Findlay S, Pace ML (1988). Bacterial production in fresh and saltwater ecosystems: a cross-system overview. Mar Ecol Prog Ser 43:1–10
Diaz RJ, Rosenberg R (2008). Spreading dead zones and consequences for marine ecosystems. Science 321:926–9. doi: 10.1126/science.1156401
Ducklow H, Steinberg D, Buesseler K (2001). Upper Ocean Carbon Export and the Biological Pump. Oceanography 14:50–58. doi: 10.5670/oceanog.2001.06
Galloway JN, Dentener FJ, Capone DG, et al. (2004). Nitrogen cycles: past, present, and future. Biogeochemistry 70:153–226.
Gray JS, Wu RS, Or YY (2002). Effects of hypoxia and organic enrichment on the coastal marine environment. Mar Ecol Prog Ser 238:249–279.
Levin LA, Ekau W, Gooday AJ, et al. (2009). Effects of natural and human-induced hypoxia on coastal benthos. Biogeosciences 6:2063–2098.
Nixon SW, Ammerman JW, Atkinson LP, et al. (1996). The fate of nitrogen and phosphorus at the land-sea margin of the North Atlantic Ocean. Biogeochemistry 35:141–180
NRC [National Research Council] (1993). Managing Wastewater in Coastal Urban Areas. Committee on Wastewater Management for Coastal Urban Areas. National Academy Press, Washington, DC
Rabalais NN (2002). Nitrogen in Aquatic Ecosystems. Ambio 31:102–112.
Socolow RH (1999). Nitrogen management and the future of food: Lessons from the management of energy and carbon. Proc Natl Acad Sci U S A 96:6001–6008.
Vaquer-Sunyer R, Duarte CM (2008). Thresholds of hypoxia for marine biodiversity. Proc Natl Acad Sci U S A 105:15452–7. doi: 10.1073/pnas.0803833105
Vitousek PM, Aber JD, Howarth RW, et al. (1997). Human alteration of the global nitrogen cycle: sources and consequences. Ecol Appl 7:737–750.
Vitousek PM, Aber JD, Howarth RW, et al. (2012). Technical Report. Ecol Appl 7:737–750.
